Definition of induction melting

Induction melting is to melt solid metal into liquid by using the heat generated by electromagnetic induction and electrothermal conversion. It is a clean, non-contact, energy-efficient and well-controlled smelting process. With the development of power industry, induction melting has been widely used in the production of metals and their alloys. The capacity, mechanization and automation level of induction smelting equipment are improving.


Crucible selection


Crucible type

Max operating temp

Applicable melting materials

Pure graphite crucible + quartz sleeve

1800 °C

Gold, silver, other precious metals

Clay graphite crucible

1600 °C

Copper

SIC crucible

1600 °C

Copper, aluminum, aluminum alloy

Magnesia crucible

2000 °C

Iron, steel, stainless steel

Zirconia crucible

2200 °C

Titanium alloy, nickel alloy


Iron ore smelting Video



Advantages of induction melting

■ Small in size, light in weight

■ Easy to operate

■ Can work 24 hours a day

■ Fast, uniform and clean melting

■ Energy saving 15-20%

■ Environmental protection - 0 pollution, 0 emissions

■ Good working environment - no open flames, low ambient temp, less oil fume

■ The smelting capacity ranges from several kilograms to several hundred kilograms


Applications of induction annealing

The induction melting system is suitable not only for factory production, but also for small-scale melting in schools and research institutes. The systems melt a wide range of metals, even ferrous to non-ferrous, such as gold, silver, copper, iron, stainless steel, steel, aluminium and aluminium alloys.
